By Alnair Laboratories Corporation
fast wavelength scanning Slot configuration allows future channel expansion Mainframes can be cascaded to accomodate over 160ch Firmware memorizes last setting for a hassle-free start-up TLG-320 features <100kHz narrow linewidth with wavelength tunability that is locked at ITU grid. It is available in main frame form, with configurations of 1 to 12 slots. The mainframe comes with an interface of USB/Ethernet. Each slot can be chosen to have 1 to 4 of laser units. Therefore, a maximum of 48 laser units can be accommodated into a main frame with 12 slots configuration. Due to its narrow linewidth, TLG-320 is ideal narrow-linewidth wavelength tunable laser source for applications such as coherent communication and long-range optical sensing. Narrow laser linewidth <100kHz C-band or L-band coverage Wavelength tunable on 25GHz ITU grid Wavelength fine-tuning resolution 1MHz Maximum of up to 48 channels slots available Optical local oscillator Coherent communication Optical sensing
O-band Ultra-Narrow, Ultra sharp Tunable Optical Filter CVF-300BO / BVF-300BO Porgrammable / Manual Features - O-band coverage 1260nm~1360nm - Narrow-ness bandwidth: min. bandwidth 50pm (6GHz) - Flexible: both bandwidth- and wavelength-tunable Applications - Automated inspection systems in prodcution lines - Narrow-band filtering for DWDM systems - Pulse-shaping and ASE-noise filtering
CATEGORY
Generate high-speed electrical pulses as short as 30ps 17ps fast rise-time for driving modulators and lasers Generate pulses on-demand or at repetition rates up to 5GHz The EPG-210 is a specially-designed short electrical pulse generator. The output pulse can be as short as 30ps, ad with the high-voltage option, it can drive most off-the-shelf laser diodes of LN modulators to generate short optical pulses. The tunability of the pulse-width and frequency repetition rate offers flexibility in laser machining application, where control of laser pulse energy is required. Short electrical pulse down to 30ps Sharp rise/fall time Adjustable pulsewidth and frequency repetition rate Triggerable from external clock Single ended or differential output available Optical pulse generation Laser diode gain-switching Laser machining LIDAR
CATEGORY
Broadband, high-power, stable ASE source VFD display for easy viewing from shallow angle Flat spectrum option available Applications: - Fiber sensing - Optical tomography - DWDM component inspection - Optical gyroscope
CATEGORY
