By Micro-Hybrid Electronic GmbH
INC5701D-360-SA-U-I Neigungssensor (6626002) | 9867.02-5.52ME Sensors for high-precision inclination measurement - Highest accuracy and resolution for precise measurements - Extremely stable measurement signal, even with strong temperature fluctuations - High EMC resistance thanks to a robust die-cast aluminum housing - Digital RS485 interface and freely scalable analog outputs Ideal for high-precision inclination measurement The INC5701D is a single-axis inclination sensor with a measuring range of up to 360°. The sensor is characterized by outstanding angular accuracy and resolution for particularly accurate and precise measurements. The industrial-grade die-cast aluminum housing enables use even in harsh environmental conditions, e.g. in the immediate vicinity of electromagnetic fields. In addition, high temperature stability ensures reliable measurements in areas with large temperature fluctuations, making the sensor ideal for outdoor applications. predestines the sensor for outdoor applications. Areas of application Thanks to their outstanding angular accuracy and resolution, the inclination sensors are used for precise measurement tasks in laboratories and industry. In production monitoring, for example, machine components are aligned with high precision using the INC5701. Simple commissioning and configuration The free sensorTOOL configuration software makes it easy to commission the inclination sensor. The sensorTOOL can be used to change parameters and display the measurement data. In addition to outputs and filtering, the measuring range can also be continuously adjusted between 0 and 360°, for example, so that the system sensitivity can be optimally adapted to the measuring task. . Variants available: INC5701D-360-SA-U-I only Technical Data Conditions Measuring axes 1 Repeatability ° ° Digital interface RS485 Ethernet PROFINET EtherCAT EtherNet / IP Switch output 0/5 V (min. 1 kΩ) Analog interface Voltage 0.5 - 4.5 V Current 4 - 20 mA Housing material Die-cast aluminum IP protection class IP67 Declaration of conformity Shock DIN EN 60068-2-27: 1500 g / 0.5 ms in 3 axes (half-sine)
Our sensor modules, consisting of highly developed inertial and gas sensors, offer precise and reliable solutions for a wide range of measurement and analysis requirements in demanding applications.
CATEGORY
The gas sensors from Micro-Hybrid offer precise and reliable measurement solutions for NDIR gas analysis and impress with their durability and adaptability.
CATEGORY
Convenient solution for the demand of small volumes offered by Micro-Sensor. Within an average 30 years’ service life of a piece of rolling stock safety requirements for rail traffic are changing. Operators must upgrade their fleets with latest sensor technology to ensure safety standards. For this so-called retrofit, often only a small number of sensors is required. Micro-Hybrid offers a convenient solution for this case and also for prototype construction or field tests. They deliver acceleration and rotation rate sensors in small series starting, e.g. 50 pieces. Micro-Sensor also develops reliable and durable sensor solutions for OEM projects with small quantities and act as your international expert in railway applications. With more than 20 years of experience and established technologies, Micro-Sensor is a specialist for inertial sensors in the regular service and develops sensors to be used in applications in harsh environments like heat, sand and a lot more. The production processes allow manufacturing of even small series. The sensors are produced modularly and adapt all necessary steps to the individual customer requirements. This decisive advantage is enabled by the deep value chain (PCB assembly, packaging, calibration) and the broad technological expertise in the corporate group of Micro-Hybrid and Micro-Epsilon.
CATEGORY
