By InRedox
Nanotubular substrates for cell culturing from Anodic Titanium Oxide
Membrane holders are designed for supporting ceramic AAO membranes in separation, filtration and transport applications. These holders feature a streamlined seal design to maintain either upstream pressure or downstream vacuum and include a smooth porous metal frit to provide seamless support required for AAO membranes under cross-membrane pressure. Application Conditions: aqueous solutions with wide range of pH, inert gases (PEEK holder with Viton® O-rings); some aqueous solutions, organic solutions and vapors, gases (Stainless Steel 304 holder with Kalrez® or Graphite O-rings) Holder Materials: PEEK; Stainless Steel (304) O-ring Materials: Viton®; Kalrez® or Graphite Temperature range: 0 to 85 °C; -20 to 300 °C (with Kalrez® O-rings) up to 700°C (with Graphite seals) Pressure range: up to 150 psi / 1000 kPa; up to 450 psi / 3000 kPa Fittings Materials: Acetal or Delrin; Stainless Steel Common Specifications: - Filtration modes: dead-end (DE) filtration; tangential flow (TF) filtration – requires special fittings - Membrane Diameter: 25 mm (with optional inserts for 13 mm membranes); 33 mm; 47 (50) mm; 90 mm - Membrane thickness: 20 to 200 μm - Holder accommodates other types of membranes - Input / Output ports: 1/8″ NPTF thread (standard); could be modified by request (custom) Standard holder kit for 25 mm AAO Membranes includes: - Top (upstream) and bottom (downstream) flanges - Stainless steel support frit - Stainless steel hardware (3 screws, 3 nuts) - Set of 10 Viton® O-rings for selected membrane size(s) - Inserts for smaller membranes (optional, purchased separately) - Fittings (purchased separately) - Instruction manual Replacement parts available: - O-rings (Viton®, Kalrez®, Graphite) - Mounting hardware - Inserts for smaller membranes sizes (i.e, 13 mm in 25 mm holder) - Fittings for dead end filtration (1/8″ or 1/4″ OD tubing to 1/8″ NPT ports) - Fittings for tangential flow filtration (2 x 1/8″ or 2 x 1/4″ OD tubing to 1/8″ NPT ports)
CATEGORY
Membrane holders are designed for supporting ceramic AAO membranes in separation, filtration and transport applications. These holders feature a streamlined seal design to maintain either upstream pressure or downstream vacuum and include a smooth porous metal frit to provide seamless support required for AAO membranes under cross-membrane pressure. - Apllication Conditions: aqueous solutions with wide range of pH, inert gases (PEEK); some aqueous solutions, organic solutions and vapors, gases (Stainless Steel 304) - Holder Materials: PEEK; Stainless Steel (304) - O-ring Materials: Viton®; Kalrez® or Graphite - Temperature range: 0 to 85 °C; -20 to 300 °C (with Kalrez® O-rings) up to 700°C (with Graphite seals) - Pressure range: up to 150 psi / 1000 kPa; up to 450 psi / 3000 kPa - Fittings Materials: Acetal or Delrin; Stainless Steel Common Specifications: - Filtration modes: dead-end (DE) filtration; tangential flow (TF) filtration – requires special fittings - Membrane Diameter: 25 mm (with optional inserts for 13 mm membranes); 33 mm; 47 (50) mm; 90 mm - Membrane thickness: 20 to 200 μm - Holder accommodates other types of membranes - Input / Output ports: 1/8″ NPTF thread (standard); could be modified by request (custom) Standard holder kit for 25 mm AAO Membranes includes: - Top (upstream) and bottom (downstream) flanges - Stainless steel support frit - Stainless steel hardware (3 screws, 3 nuts) - Set of 10 Viton® O-rings for selected membrane size(s) - Inserts for smaller membranes (optional, purchased separately) - Fittings (purchased separately) - Instruction manual Replacement parts available: - O-rings (Viton®, Kalrez®, Graphite) - Mounting hardware - Inserts for smaller membranes sizes (i.e, 13 mm in 25 mm holder) - Fittings for dead end filtration (1/8″ or 1/4″ OD tubing to 1/8″ NPT ports) - Fittings for tangential flow filtration (2 x 1/8″ or 2 x 1/4″ OD tubing to 1/8″ NPT ports) Price range: $75.00 through $1,945.00
CATEGORY
Set of 10 O-rings for Electrodeposition Holder to accommodate 25 mm AAO wafers with contacts. The set includes: - 5 O-rings for inner seal to 25 mm AAO - 5 O-rings for outer seal The O-rings feature double seal design, ensuring a reliable seal and well-defined surface area.
