ADCA Series. Product Family: ADCA. Product Output: Analog Amplified. Product Grade: STANDARD. Package Type: A. Media Isolated Coating: No. Pressure Type: Differential. Pressure Min: -1. Pressure Max: 1. Units: MBAR. Supply Voltage: 5 VS. Operating Temperature: -40C to 125 C
The Amphenol All Sensors BFTM series leverages proprietary technology to minimize size while maintaining superiorperformance. These sensors significantly reduce output offset errors caused by position sensitivity, packaging stress,and long-term drift compared to conventional silicon sensors. Featuring a silicon, micromachined, stress-concentration-enhanced structure, the BFTM series provides a highly linear output to measured pressure. Designed for use with non-corrosive, non-ionic working fluids such as air and dry gases, these sensors offer a ratio-metric output proportional to the supply voltage, ensuring high precision and reliability for demanding applications. With their compact design and enhanced accuracy, BFTM basic pressure sensors are ideal for industries requiringreliable pressure measurement, including industrial, and environmental monitoring applications. Experience the next level of precision with the BFTM Series by Amphenol All Sensors. Consult with one of ourapplications specialists to assess if the BFTM series is the right sensing solution for your needs. Features - Ultrastable and Compact Design - Enhanced Accuracy - Optimized packaging for high common mode & low differential pressure monitoring - Combined Absolute and Differential pressure in single package - RoHS Compliant Ratings Supply Voltage VS 6 Vdc Lead Temperature (soldering 2-4 sec.) 270°C Temperature Ranges - Operating -25 to 85° C - Storage -40 to 125° C Humidity Limits 0 to 95% RH (non condensing) Specifications Supply Voltage VS 6 Vdc Lead Temperature (soldering 2-4 sec.) 270°C Temperature Ranges - Operating -25 to 85° C - Storage -40 to 125° C Humidity Limits 0 to 95% RH (non condensing)
CATEGORY
This innovative sensor is specifically designed to provide high accuracy, dual airspeed and altitude pressure sensing in a single printed circuit board mount package. This significant advancement not only combines two (2) sensors in a single package but reduces overall size resulting in payload capacity improvement for size and weight restricted unmanned aerial vehicle (UAV) technology. The sensor is the result of rigorous research and development efforts aimed at meeting the demanding requirements of both commercial and defense UAV applications. Leveraging the extensive expertise in advanced sensing technologies, the AUAV Pressure Sensor offers state-of-the-art performance and reliability. Both Sensing elements are digitally compensated and provide Low power digital I2C outputs and unique serialized addressing for self-test, predictive monitoring and redundant safety requirements where needed. Key Features and Benefits: - Dual Functionality: The AUAV Pressure Sensor uniquely combines airspeed and altitude measurement capabilities in a single compact unit, offering exceptional efficiency, accuracy and stability - High Precision: Utilizing MEMS piezoresistive technology, the sensor ensures high-precision data for critical UAV navigation and control systems. - Robust Design: Engineered for durability, the AUAV Pressure Sensor withstands harsh environmental conditions, ensuring reliable performance in diverse operational contexts. - Sustainability and Safety: In line with Amphenol's commitment to quality, safety, and environmental protection, the AUAV Pressure Sensor is designed with sustainable materials and practices, ensuring minimal environmental impact while maintaining the highest safety standards. - Unique serialized addressing for self-test, predictive monitoring and redundant safety requirements where needed.
CATEGORY
The ELVX Digital Pressure Sensor Series are leadless with dual die configuration which provides best-in-class stability for low and ultra-low pressure applications. These calibrated and compensated sensors provides accurate and stable output over a wide temperature range. This series is intended for use with non-corrosive, non-ionic working fluids such as air and other dry gases. A protective parylene coating is optionally available for moisture/harsh media protection. For more information or to discuss your specific application needs, please contact our application experts who will assist you in selecting the right solution for your pressure-sensing needs. Features - ± 0.5 inH2O to ± 60 inH2O - Gage or Differential Pressure - Precision ASIC Conditioning - Digital I2C and SPI Options - 3.3V and 5V Supply Voltage Options - PCB Surface Mount - Improved Warm-up Stability Ratings Supply Supply Voltage VS 2.7 to 5.5 Vdc Device Temperature (Reflow Soldering) 250° C [482° F] Specifications Temperature Ranges - Compensated - Standard 0 to 50° C [32 to 122° F] Compensated - Industrial -20 to 85° C [-4 to 185° F] Operating -25 to 85° C [-13 to 185° F] Storage -40 to 125° C [-40 to 185° F]
CATEGORY
The ELVH Series Pressure Sensors are based on All Sensors’ ultra low pressure CoBeam 2 TM Technology. This innovative sensing element technology provides pressure sensors with best in class ultra low pressure sensing which reduces pack age stress susceptibility, resulting in improved overall long term stability and vastly improved position sensitivity. The ELVH series gives design engineers outstanding flexibility with the variety of choices in package combination. The digital interface eases integration of the sensors into a wide range of process control and measurement systems, allowing direct connection to serial communications chan nels. For battery-powered systems, the sensors can enter very low-power mode between readings to minimize load on the power supply. These calibrated and compensated sensors provide accurate, stable output over a wide temperature range. This series is intended for use with non-corrosive, non-ionic working fluids such as air, dry gases. A protective parylene coating is optionally available for moisture/harsh media protection for pressure ranges starting at ±25 mbar and above. Features - 0.5 up to 30 inH2O and 1 up to 150 psi and 100 mbar up to 10 bar - Digital I2C or SPI in 14 Bit Output with Analog Option - 3.3V or 5V Supply Voltage Options - All Sensors' Superior, Dual-Die CoBeam 2 TM Technology - Various Lead and Port Options Available Ratings Supply Voltage VS 2.7 to 5.5 Vdc Maximum Device Temperature 245°C Specifications Temperature Ranges Compensated - Standard 0 to 50°C Compensated - Industrial -20 to 85°C Operating -25 to 85°C Storage -40 to 125°C Humidity Limits (non condensing) 0 to 95% RH
CATEGORY
