Controlling Cells with a Laser Beam


Star shaped patters are created (left), into which the cells can grow (right). @ TU WIEN

It is one of the biggest problems with producing artificial tissue: How can the individual cells be directed to the right place, for example when a blood vessel is to be created at a very specific location? This feat has now been achieved at TU Wien (Vienna): The hydrogel surrounding the cells is enriched with very special molecules that can then be activated with a laser beam. The hydrogel then becomes softer and more permeable at precisely these points, so it is possible to determine exactly where the cells should move.


The new technique is particularly interesting for pharmaceutical research without animal testing: with this laser method, special tissue systems can be produced in a reproducible way, which can then be examined under precisely controlled conditions on a chip, for example to test new drugs.


Like a gummy bear in water


"When making tissue constructs in the lab, you often start with living cells embedded in a hydrogel," says Prof. Aleksandr Ovsianikov, head of the 3D Printing and Biofabrication research group at TU Wien. The hydrogel is a biocompatible material, with properties very similar to those of biological tissue. "Comparable to a gummy bear soaked with water," Ovsianikov explains. The cells can migrate through the hydrogel and form a tissue. However, it would be desirable to be able to control this process and have the cells adhere to a predetermined blueprint.


In the research group for 3D printing and biofabrication, however, very special molecules have now been added to the hydrogel. Normally, they do not change the behaviour of the hydrogel, but when they are activated with a laser at a specific location, the hydrogel becomes softer and more permeable at precisely this point. "The molecule couples to the network of the hydrogel, at this point the network becomes more hydrophilic. This changes the physical properties, and in this way it is possible to create a 3D pattern through which the cells can pass more easily than elsewhere," explains Simon Sayer (TU Wien).


That way, the laser beam was used to predetermine certain paths in the hydrogel - and indeed the cells migrated exactly along exactly these paths. In this way, star-shaped or lattice-shaped cell structures could be produced.


Human on a Chip


For the time being, the focus of this research is not necessarily on the creation of artificial organs, but on a technology that is often called "organ on a chip" or "human on a chip": Tissue parts are created, which then interact with each other. They are placed on a chip of a few centimeters in size and can be supplied with very specific nutrients or also with pharmaceutical compounds in a highly precise manner. In this way, one can gather important information about the effect of drugs without having to resort to animal testing. In addition, one can work with human cells, which makes the results much more meaningful.


"But this only works if we can precisely control the properties of these tissues," says Tommaso Zandrini (TU Wien). "Firstly, these experiments need to be reproducible, so you want several tissue samples with exactly the same microstructure, and secondly, you also need to be able to precisely connect the different samples - for example, if you're studying the interaction between a small piece of heart muscle tissue and a small piece of liver tissue." To understand the interaction accurately, structures such as blood vessels need to be in exactly the right place. This is now possible with this new laser method. The complexity of customized tissue samples can therefore be drastically increased.


Reference

Simon Sayer, Tommaso Zandrini, Marica Markovic, Jasper Van Hoorick, Sandra Van Vlierberghe, Stefan Baudis, Wolfgang Holnthoner & Aleksandr Ovsianikov

Scientific Reports volume 12, Article number: 8626 (2022)


Contact

Prof. Aleksandr Ovsianikov

Institut für Werkstoffwissenschaften und Werkstofftechnologie

Technische Universität Wien

+43 1 58801 30830
