A new dimension in chemical nanoimaging



An ultimate goal in materials science, biomedicine or nanotechnology is the non-invasive compositional mapping of materials with nanometer-scale spatial resolution. A variety of high-resolution imaging techniques exist (for example, electron or scanning probe microscopies), however, they cannot meet the increasing demand in research, development and industry of being noninvasive while offering highest chemical sensitivity.

Nanoscale chemical analysis has recently become possible with nano-FTIR spectroscopy, an optical technique that combines scattering-type scanning near-field optical microscopy (s-SNOM) and Fourier transform infrared (FTIR) spectroscopy. By illuminating the metalized tip of an atomic force microscope (AFM) with a broadband infrared laser or a synchrotron, and analyzing the backscattered light with a specially designed Fourier Transform spectrometer, local infrared spectroscopy with a spatial resolution of less than 20 nm has been demonstrated. However, only point spectra or spectroscopic line scans comprising not more than a few tens of nano-FTIR spectra could be achieved on organic samples, owing to the long acquisition times.

Now, researchers from CIC nanoGUNE (San Sebastian, Spain), Ikerbasque (Bilbao, Spain), Cidetec (San Sebastian, Spain) and the Robert Koch-Institut (Berlin, Germany) developed hyperspectral infrared nanoimaging. The technique allows for recording two-dimensional arrays of several thousand of nano-FTIR spectra - usually referred as to hyperspectral data cubes - in a few hours and with a spatial resolution and precision better than 30 nm.

"The excellent data quality allows for extracting nanoscale-resolved chemical and structural information with the help of statistical techniques (multivariate data analysis) that use the complete spectroscopic information available at each pixel", says Iban Amenabar, first author of the work. Even without any previous information about the sample and its components, pixels with similar infrared spectra can be grouped automatically with the help of hierarchical cluster analysis. By imaging and analysis of a three-component polymer blend and (Figure 1), the researchers obtained nanoscale chemical maps that do not only reveal the spatial distribution of the individual components but also spectral anomalies that were explained by local chemical interaction. The researcher also demonstrated in situ hyperspectral infrared nanoimaging of native melanin in human hair.

For their experiments, the researchers used the commercial nano-FTIR system from Neaspec GmbH including a mid-infrared laser continuum that covers the spectral range from 1000 to 1900 cm-1. Multivariate analysis of the hyperspectral data was done with the software tool CytoSpec, which was developed by coauthor Peter Lasch.

"With the rapid development of high-performance mid-infrared lasers and by applying advanced noise reduction strategies, we envision high-quality hyperspectral infrared nanoimaging in few minutes", concludes Rainer Hillenbrand who led the work. "We see a large application potential in various fields of science and technology, including the chemical mapping of polymer composites, pharmaceutical products, organic and inorganic nanocomposite materials or biomedical tissue imaging ", he adds.

Hyperspectral infrared nanoimaging of organic samples based on Fourier transform infrared nanospectroscopy Iban Amenabar, Simon Poly, Monika Goikoetxea, Wiwat Nuansing, Peter Lasch & Rainer Hillenbrand Nature Communications 8, Article number: 14402 (2017) doi:10.1038/ncomms14402

Elhuyar Fundazioa
